All most never will the coils (the heavy part you can't fix) be the problem. You can open any transformer and measure where voltage is or is not and debug the circuit. Transformers can also use a fuse and or a reset (circuit breaker) switch. If you are not able to ohm the circuit, You can jumper the power supply around the switches. Photocell, Timer, Switch, are all switches. Verify power supply is off to transformer. UN-PLUG FIRST! If hard wired, MAKE CERTAIN POWER IS OFF! With a multimeter you can ohm around the switches.

If the photocell is exposed to enough light at night, street lights etc.

The power wires will show High resistance when the photocell lens is NOT taped over. The power wires will show no resistance when the photocell lens is taped over.

A multimeter can be used to ohm out the two power wires.

A photocell is a light sensitive switch, and can take seconds to minutes to switch on.

Cover over the lens on the photocell with black tape.

2 wires attached to the photocell are power in and power out.

Most transformers in place today get power to the primary winding through the photocell. Check the wiring to and from from the photocell. You will be looking to see AC power to the primary winding of the transformer. If you do not have a photocell but switch or timer, wiring will be nearly the same. What we are looking for is switches in the circuit pass AC power to the primary winding of the transformer when they are supposed to. Verify that the Photocell, Timer, Switch Operate Properly You get better design, clean contacts, and save time. Note: At any time along the way, if you are apprehensive, a new transformer is the way to go. This means you need to open up the cover, access the wire that feeds the transformer. Verify AC power to primary winding of transformer (primary winding is where plug wires connect to transformer), then go to step two.

12 volt landscape lighting power units manual#

For now select manual operation, which means not to use photo cell or timer. You should have an option to turn the transformer on manually. Photo cell, timer, switch failure is a common cause of transformer malfunction. If the transformer uses a photocell, timer, switch.

Switches get dirty, corroded, loose wires etc.) (you may need to come back to this later to make sure it works.

If the transformer has an ON/OFF switch, turn it on. If you don't have any electrical sensor, plug a light or power tool into the outlet. Verify the transformer is plugged or wired to a working power source of correct voltage. Some transformers are wired directly from the wall mount. Most transformers plugs into an outlet, usually 120 AC.

Move to each consecutive light checking voltage.

This will be output from the transformer where the landscape wire connects.

First check the voltage at the secondary.

12 volt landscape lighting power units how to#

How to test low voltage lighting with multimeter?

12 volt landscape lighting power units install#

Common install is transformer in the garage, and drill a 3/8 inch hole allowing photo cell to be outside. Allows the transformer be mounted more out of the elements, and the photo cell in a more optimum location. Many if not mode newer transformers have a plug in jack for use with a remote photo cell.This type relies on the transformer location for proper function. Photocell located on the transformer case on the case.Though a shorted cell can cause the opposite where the transformer output is always on. When a photo cell fails it causes an "OPEN" in the circuit.Landscape lighting transformer with photo cell? You will normally see them on the primary side.

Fuses are less likely in newer transformers.

I usually just needs be pushed in to reset.

A reset button is like a circuit breaker in that it trips.

Some transformers will have a fuse or reset button.

If no voltage to secondary then it is likely the transformer is no good.

Check for photo cell and cover with tape to imitate darkness.

Check power exists to the primary side.

How do I know if my low voltage transformer is bad? Outdoor lighting provides illumination to draw attention and attraction, to homes, buildings and premises, for cosmetic and security benefits. This article explains how to trouble shoot and repair an outdoor lighting system.

Get Power From Secondary To Landscape Wire.

Low Voltage Transformer Troubleshooting Table of Contents
